Application example – Ensemble Designs BrightEye 81 3G / HD / SD SDI to HDMI Converter User Manual
Page 6
www.ensembledesigns.com
BrightEye 81 - Page 6
81
3G/HD/SD SDI to HDMI Converter
Application Example
The application example below shows a BrightEye 81 being used to convert a camera’s 3G video signal
to HDMI and feed an ISO monitor. In addition, two SDI outputs are provided. They follow the input
signal and are identical, in this case providing 3G signals to feed other destinations.
BrightEye 81
3G HD SDI
Router
HDMI
SDI Out 1
SDI Out 2
Camera
ISO Monitor
3G HD SDI
HDMI Out
to another 3G HD SDI Destination
BrightEye 81 3G HD SDI to HDMI Conversion Example
