MODULE CONFIGURATION AND CONTROL
The parameters for each Avenue module must be configured after installation. This can be
done remotely using one of the Avenue remote control options or locally using the module
front panel controls. Each module has a REMOTE/LOCAL switch on the front edge of
the circuit board which must first be set to the control mode you will be using.
The configuration parameter choices for the module will differ between Remote and
Local modes. In Remote mode, the choices are made through software and allow more
selections. The 6030 Parameter Table below summarizes and compares the various con-
figuration parameters that can be set remotely or locally and the default/factory settings.
If you are not using an remote control option, the module parameters must be configured
from the front panel switches. Parameters that have no front panel control will be set to a
default value. The Local switches are illustrated in the Front Panel Controls and
Indicators section following the 6030 Parameter Table.
Avenue module parameters can be configured and controlled remotely from one or both of
the remote control options, the Avenue Touch Screen or the Avenue PC Application. Once
the module parameters have been set remotely, the information is stored on the module
CPU. This allows the module be moved to a different cell in the frame at your discretion
without losing the stored information. Remote configuration will override whatever the
switch settings are on the front edge of the module.
For setting the parameters remotely using the Avenue PC option, refer to the Avenue PC
Remote Configuration section of this document.
For setting the parameters remotely using the Avenue Touch Screen option, refer to the
Avenue Touch Screen Remote Configuration section of this data pack following
Avenue PC.
Model 6030 Video-Referenced AES/Word Clock Generator
6030-7
Video Standard
Lock Mode
Ref Source
Loss of Ref
NTSC
PAL
Auto Switch
Internal
Module Ref
Tray Ref
Free run
Mute Output
Front Panel Switch:
PAL (right)
NTSC (left)
Front Panel Switch:
Int (right)
Auto (left)
Front Panel Switch:
Tray Ref (On - right)
(Off - left)
Front Panel Switch:
Mute (On - right)
(Off - left)
N/A
N/A
N/A
N/A
CONTROL REMOTE LOCAL DEFAULT VALUE
6030 Parameter Table
