  • Text mode
  • Original mode
background image

Troubleshooting

Page 88

2

Lay the clear document guide on the document table with
the oval hole on the right and the round hole on the left.
Align the holes on the guide over the pins.

adjust pin

guide pin

clear document guide

arrow
