Installing the transparency guide – Epson 836XL User Manual
Page 36
Using Optional Equipment
Page 36
Installing the Transparency Guide
Follow the steps below to install the transparency guide:
1
Lift the TPU.
2
If your scanner doesn’t already have a guide pin and
adjust pin installed as shown below, insert the guide pin
and adjust pin that came with the TPU. Make sure the
adjust pin’s arrow faces the guide pin.
adjust pin
guide pin
arrow
