Using Optional Equipment Page 50
Scanning Normal Documents with the
Transparency Unit Installed
To scan normal documents with the TPU installed, insert the
reflective document mat included with the TPU as described
below.
1 Open the TPU and remove the transparency guide from
the scanner’s document table, if necessary.
2 Slide the reflective document mat into place and insert the
tabs into the slots on the TPU as shown below. Then firmly
pull up the mat while inserting the top two tabs into the
slots in the top of the TPU.
tabs go into slots here
pull up into slots here
