The front panel menu allows you to configure input mapping and baud rates. It can also reset the device to
factory defaults, and is the only place on the device to access the autobaud function.
Menu and configuration options are displayed on the Level 1 and Level 2 LEDs on the faceplate. Navigate
through the menu using the mode switch:
1 Press and hold the mode switch to enter Menu mode. The Level 1 LEDs will start to light up to indicate
that the device is cycling through all menu options.
2 When the LEDs light up in the way that indicates the menu option you want (see the figure below),
release the mode switch.
3 Quickly press and release the mode switch to select the current menu option. The Level 2 LEDs will
light up to let you configure the options for the selected menu option.
4 Press and hold the mode switch to cycle through available values for the selected menu option. The
Level 2 LEDs display the currently selected value.
5 Press and release the mode switch to accept the displayed value. The device will exit the menu.
See the figure below for how to use the LEDs to configure the parameter.
Channel Input Mapping
This function lets you map four of the input
data channels coming from the sensor to the
four output channels on the device. See part 5
for more information.
NOTE: If this is set with the rotary switch, you
won’t be able to change it with the front panel
menu.
Autobaud
This function initiates an autobaud on the
RS-485 bus you select. If the autobaud is suc-
cessful, the LEDs will display the baud rate
found, using the same LED patterns used for
the baud rate (see figure above). If it fails, all
four LEDs will flash, and then the device will
exit the menu.
Baud Rate for Bus 1 and Bus 2
This function lets you set the baud rate for bus
1 and bus 2. The two buses can be configured separately.
Reset to Default
This function will restore all configuration settings to factory defaults (even those not configured using the
front panel menu): baud rate, channel map, description field, location field and device ID.
7
Configuration option 2: front panel menu
Input Mapping
Menu LEDs
Cancel
1-4
5-8
9-12
13-16
17-20
21-24
25-28
29-32
33-36
1 2 3 4
R B G Y
Rotary
Switch
= SW 0
= 1-4
= 5-8
= 9-12
= 13-16
= 17-20
= 21-24
= 25-28
= 29-32
= 33-36 1
2
3
4
5
6
7
8
9
Bus 1 Baud Rate
R B G Y
Menu LEDs
Cancel
9600
19200
38400
57600
1 2 3 4
Bus 2 Baud Rate
R B G Y
Menu LEDs
Cancel
9600
19200
38400
57600
1 2 3 4
Autobaud
R B G Y
Menu LEDs
Cancel
Bus 1
Bus 2
1 2 3 4
Reset to Default
= LED Off
= LED Flashing
= LED On
R B G Y
Menu LEDs
Cancel
Reset
1 2 3 4
Menu Operation •
PUSH and HOLD Mode Switch to
cycle through menus and options.
•
PUSH and
RELEASE
Mode Switch
to make
selections.
• 1 minute of
inactivity exits
menu.
5 4 3 2 1
09
8 7
6
This label is also on the side of the Click 104
