Sundance SMT370v2 User Manual
Page 37
Version 2.0
Page 37 of 46
SMT370v2/v3 User Manual
Register 0x6 – Channel selection – Triggers – Decimator for ADCs.
Bit number
Description
Bit 31
0
Bit 30
1
Bit 29
1
Bit 28
0
Bit 27
Not Used.
Bit 26
Bit 25
Bit 24
Decimation Factor Channel B – Bit 4
Bit 23
Decimation Factor Channel B – Bit 3
Bit 22
Decimation Factor Channel B – Bit 2
Bit 21
Decimation Factor Channel B – Bit 1
Bit 20
Decimation Factor Channel B – Bit 0
Bit 17-19
Bit 16
Decimation Factor Channel A – Bit 4
Bit 15
Decimation Factor Channel A – Bit 3
Bit 14
Decimation Factor Channel A – Bit 2
Bit 13
Decimation Factor Channel A – Bit 1
Bit 12
Decimation Factor Channel A – Bit 0
Bit 11
Bit 10
Bit 9
External Trigger Level (‘0’=Active low; ‘1’=Active high)
Bit 8
External Trigger Enable (‘0’=External Trigger Disabled; ‘1’=Enabled)
Bit 7
Not Used.
Bit 6
Channel A Selection Enable – Bit 2.
Bit 5
Channel A Selection Enable – Bit 1.
Bit 4
Channel A Selection Enable – Bit 0.
Bit 3
Not Used.
Bit 2
Channel B Selection Enable – Bit 2.
Bit 1
Channel B Selection Enable – Bit 1.
Bit 0
Channel B Selection Enable – Bit 0.
