Model 58/591 User Guide Issue 1, September 1999
Studio Technologies, Inc. Page 39
Function: Input Source and Associated Channels
Byte Value Description
1 F0H System-Exclusive Message
2 00H 1 st Byte of Studio Tech ID
3 00H 2 nd Byte of Studio Tech ID
4 56H 3 rd Byte of Studio Tech ID
5 03H Product ID (Model 58)
6 01H Function, Input Source and Associated Channels
7 0nH Input Source, range 1-8, 1=input source 1, 2=input source 2, etc.
8 nnH Input Channel Status Bit Map (sum values from all seven channels):
Channel 1: off=00; on=01
Channel 2: off=00; on=02
Channel 3: off=00; on=04
Channel 4: off=00; on=08
Channel 5: off=00; on=10
Channel 6: off=00; on=20
Channel 7: off=00; on=40
9 0nH Input Channel Status
Channel 8: off=0; on=1
10 F7H EOX, End of System Exclusive
