9. MAINTENANCE
WARNING!! NEVER SERVICE HEATER WHILE IT IS PLUGGED IN
OR WHILE HOT!
USE ORIGINAL EQUIPMENT REPLACEMENT PARTS. Use of third party
or other alternate components will void warranty and may cause unsafe
operating conditions.
A.) UPPER SHELL REMOVAL
B.) FAN BLADES AND AIR DEFLECTOR
CLEAN EVERY SEASON OR AS NEEDED.
- Remove upper shell (See figure 7 above)
- Clean fan blades and air deflectors using a soft cloth
moistened with kerosene or solvent.
- Dry fan blades and air deflectors thoroughly.
- Reinstall upper shell.
AIR DEFLECTOR
FAN BLADE
Figure 8. Fan Blades and Air Deflectors
-Remove screws along each side and top of
heater using medium phillips screw driver.
-Lift upper shell off.
(See Figure 7)
Figure 7. Upper Shell Removal
9
Shell Upper
Screw
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
