3-4 •••• User Controls ADC-8432 User Manual (Rev. 1.1)
DIP SW3, SW4 and SW5 — Internal Sample Rate
SW3, SW4, and SW5 are used in combination to set the internal sample reference rate. Ensure
that
SW1 and SW2 are both set to the ON position. Table 2 lists the combinations for SW3,
SW4 and SW5.
Table 2. DIP SW3, SW4 and SW5 Settings Descriptions
SW3
(SR SEL
MSB)
SW4
(SR SEL)
SW5
(SR SEL
LSB)
Description
OFF
OFF OFF 32kHz
OFF OFF ON 44.1kHz
OFF ON OFF 48kHz
OFF ON ON 96kHz
ON -- -- 192kHz
DIP SW6
This feature is not yet implemented.
DIP SW7 — Default DIP Switch/Memory
SW7 is used to enable or disable the parameters set by the DIP Switches on the ADC-8432.
Set SW7as follows:
• ON — Select this setting to retrieve the ADC-8432 parameters from the non-
volatile memory. The DIP Switch settings are ignored.
• OFF — Select this setting to enable the ADC-8432 to retrieve parameters from
the DIP Switches.
DIP SW8 — DashBoard Disable
SW8 is used to disable remote control of the ADC-8432 from the DashBoard Control System.
Set SW8 as follows:
• ON — Select this setting to disable remote control from DashBoard. The
parameters and settings cannot be changed via DashBoard and must be changed
using the card controls. You can still monitor the status of the card using
DashBoard.
• OFF — Select this setting to control the ADC-8432 exclusively from
DashBoard. The card controls are ignored.
