Dell Vostro 15 3558 - Manual (Page 48)

Feature Description
Y-axis 80.00 mm (3.14 inches)
Table 25. Battery
Feature Description
Type • 4-cell “smart” lithium ion (47 WHr)
Dimensions:
Height 20.00 mm (0.78 inch)
Width 270.00 mm (10.63 inches)
Depth 37.50 mm (1.47 inches)
Weight 0.26 kg (0.56 lb)
Life span 300 discharge/charge cycles
Voltage 14.80 VDC
Temperature range:
Operating 0 °C to 35 °C (32 °F to 95 °F)
Non-Operating –40 °C to 65 °C (–40 °F to 149 °F)
Coin-cell battery 3 V CR2032 lithium ion
Table 26. AC Adapter
Feature Description
Type 45 W
65 W
Input voltage 100 VAC to 240 VAC
Input frequency 50 Hz-60 Hz
Input current (maximum)
45 W 1.30 A
65 W 1.70 A
Output current
45 W 2.31 A
65 W 3.34 A
Rated output voltage 19.50 VDC
Temperature range:
Operating 0 °C to 40 °C (32 °F to 104 °F)
Non-Operating –40 °C to 70 °C (–40 °F to 158 °F)
48
