Electrical characteristics curves (con.) – Delta Electronics Delphi NC30 User Manual
Page 4
DS_NC12S30A_05222008
4
ELECTRICAL CHARACTERISTICS CURVES (CON.)
0
20
40
60
80
100
120
0
2
4
6
8
10 12 14 16 18 20 22 24 26 28 30
Output Current (A)
E
ffi
ci
en
cy
(
%
)
10.2
12
13.8
Figure 7:
Converter efficiency vs. output current
(5.0V output voltage)
Figure 8:
Output ripple & noise at 12Vin, 0.9V/30A out
Figure 9:
Output ripple & noise at 12Vin, 1.2V/30A out
Figure 10:
Output ripple & noise at 12Vin, 1.5V/30A out
Figure 11:
Output ripple & noise at 12Vin, 1.8V/30A out
Figure 12:
Output ripple & noise at 12Vin, 2.5V/30A out
