49
AMPLIFIER SECTION
• Power output, stereo mode, 8 Ω, THD 0.05%, 20 Hz~20 kHz | 2 100 W
• Total harmonic distortion, 8
Ω, 100 W, 1 kHz | 0.05 %
• Intermodulation distortion
60 Hz : 7 kHz = 4 : 1 SMPTE, 8 Ω, 100 W | 0.09 %
• Input sensitivity/impedance
Line (CD, TAPE, VIDEO) | 200 mV/47 k Ω
• Signal to noise ratio, IHF “A” weighted
Line (CD, TAPE, VIDEO) | 98 dB
• Frequency response
LINE (CD, TAPE, VIDEO), 10~100,000 Hz | +0, -3 dB
• Output level
TAPE REC, 1 k Ω | 180 mV
PRE OUT(Front, Center, Surround, Surround back, Subwoofer), 1 k Ω | 1.0 V
• Bass/Treble control, 100 Hz/10 kHz | ±10 dB
• Surround mode, only channel driven
Front power output, 8 Ω, 1 kHz, THD 0.7 % | 110 W+110 W
Center power output, 8 Ω, 1 kHz, THD 0.7 % | 110 W
Surround power output, 8
Ω, 1 kHz, THD 0.7 % | 110 W+110 W
Surround back power output, 8 Ω, 1 kHz, THD 0.7 % | 110 W+110 W
DIGITAL AUDIO SECTION
• Sampling frequency | 32, 44.1, 48, 96, 192 kHz
• Digital input level
Coaxial, 75 Ω | 0.5 Vp-p
Optical, 660 nm | -15~-21 dBm
VIDEO SECTION
• Video format | PAL
• Input sensitivity(=Output level), 75
Ω
Video(Composite (normal)) | 1 Vp-p
S-Video(luminance signal) | 1 Vp-p
(chrominance signal) | 0.286 Vp-p
Component video(R-Y signal) | 0.5 Vp-p
(B-Y signal) | 0.5 Vp-p
(Y signal) | 1.0 Vp-p
FM TUNER SECTION
• Tuning frequency range | 87.5~108 MHz
• Usable sensitivity, THD 3 %, S/N 26 dB | 17.2 dBf
• 46 dB quieting sensitivity, mono/stereo | 25.2/43.2 dBf
• Signal to noise ratio, 65 dBf, mono/stereo | 72/68 dB
• Total harmonic distortion, 65 dBf, 1 kHz, mono/stereo | 0.2/0.3 %
• Frequency response, 20 Hz~15 kHz | ±1.5 dB
• Stereo separation, 1 kHz | 45 dB
• Capture ratio | 3.0 dB
• IF rejection ratio | 120 dB
AM TUNER SECTION
• Tuning frequency range | 522~1611 kHz
• Usable sensitivity | 12.5 mV
• Signal to noise ratio | 51dB
• Selectivity | 30 dB
GENERAL
• Power supply | AC 230 V, 50 Hz
• Power consumption | 370 W
• Switched AC outlet | TOTAL 100 W max.
• Dimensions(W
H D) | 440 166 380 mm(17-3/8 6-1/2 15 inches)
• Weight(Net) | 17.3 kg(38.1 lbs)
Note: Design and specifications are subject to change without notice for improvements.
Specifications
