DTS RV4700 DTS-ES - Manual (Page 40)

40
Press the CURSOR LEFT( )/RIGHT( ) buttons to select the desired DIGITAL IN.
4
• Each time these buttons are pressed, the DIGITAL INs change.
Notes:
• Because there are 5 DIGITAL INs on the rear and front panels,
one of CD, TAPE MONITOR and VIDEO 1~4 cannot be
matched a DIGITAL IN to.
In this case, you do select “None” instead of a DIGITAL IN.
• When the input source set to “None” is selected, the analog
input is automatically selected.
• In such a case that a DIGITAL IN is matched to two input
sources or more, when these input sources are selected, the
digital audio signals can be heard from the same DIGITAL IN.
• Each time these buttons are pressed, the video input
source changes.
When selecting the VIDEO SELECT
• You can also select a video input source on the OSD menu and enjoy it without pressing the VIDEO SELECTOR
button(s).
DVD
VOL. CH LEVEL
CH SEL
DSP MODE
AUTO
ST CENTER MODE TEST TONE DISC P.SCAN
TUNER CD T1/MON AUX PHONO
VID1 VID2 VID3 VID4 VID5
SYS DISP SLEEP DIRECT IN ROOM2
INTRO
RETURN
B RPT A
7.1 SURR TITLE
ENTER
ENTER V I D E O I N : VID 1
V I D E O S E L E C T
R E T U R N : B a c k , : S e l e c t
HOME THEATER MASTER RV4700 DTS-ES
DVD
VOL. CH LEVEL
CH SEL
DSP MODE
AUTO
ST CENTER MODE TEST TONE DISC P.SCAN
TUNER CD T1/MON AUX PHONO
VID1 VID2 VID3 VID4 VID5
SYS DISP SLEEP DIRECT IN ROOM2
INTRO
RETURN
B RPT A
7.1 SURR TITLE
ENTER
HOME THEATER MASTER RV4700 DTS-ES
Repeat the above steps and until the connected DIGITAL INs are matched to the desired input
sources respectively. 5
Press the CURSOR UP( )/DOWN( ) buttons to select the VIDEO SELECT, then press the ENTER
button. 2
Press the CURSOR LEFT( )/RIGHT( ) buttons to select the desired video input source.
3
DVD
VOL. CH LEVEL
CH SEL
DSP MODE
AUTO
ST CENTER MODE TEST TONE DISC P.SCAN
TUNER CD T1/MON AUX PHONO
VID1 VID2 VID3 VID4 VID5
SYS DISP SLEEP DIRECT IN ROOM2
INTRO
RETURN
B RPT A
7.1 SURR TITLE
ENTER
HOME THEATER MASTER RV4700 DTS-ES
