41
• Each time these buttons are pressed, the tone defeat mode
changes as follows:
On : Select this when listening to a program source without
the tone effect.
Off : Select this when adjusting tone for your taste.
Note:
• When the tone defeat mode is set to On, the tone (bass and
treble) cannot be adjusted.
T O N E D E F E A T :
DVD
VOL. CH LEVEL
CH SEL
DSP MODE
AUTO
ST
CENTER MODE TEST TONE DISC P.SCAN
TUNER CD T1/MON AUX PHONO
VID1 VID2 VID3 VID4 VID5
SYS DISP SLEEP DIRECT IN ROOM2
INTRO
RETURN
B RPT A
7.1 SURR TITLE
ENTER
ENTER
Off
T O N E C O N T R O L
R E T U R N : B a c k , : S e l e c t
B A S S - - - - - + - - - - - 0 dB
T R E B L E - - - - - + - - - - - 0 dB
HOME THEATER MASTER RV4700 DTS-ES
Press the CURSOR UP( )/DOWN( ) buttons to select the TONE CONTROL, then press the ENTER
button. 1
Press the CURSOR LEFT( )/RIGHT( ) buttons to select the desired tone defeat mode.
2
When selecting the TONE CONTROL
When the tone defeat mode is set to Off to adjust the tone (bass and treble)
1. Press the CURSOR UP( )/DOWN( ) buttons to select the desired tone mode.
• Each time these buttons are pressed, “ ” is moved to the tone defeat mode or the corresponding tone mode.
2. At the desired tone mode, press the CURSOR LEFT( )/RIGHT( ) buttons to adjust the selected tone as desired.
• The tone level can be adjusted within the range of -10~+10 dB.
• In general, we recommend the bass and treble to be adjusted to 0 dB(flat level).
• Extreme settings at high volume may damage your speakers.
3. To complete tone adjustment, repeat the above steps 1 and 2.
Note:
• When the source direct function is activated, the TONE CONTROL cannot be selected.
DVD
VOL. CH LEVEL
CH SEL
DSP MODE
AUTO
ST CENTER MODE TEST TONE DISC P.SCAN
TUNER CD T1/MON AUX PHONO
VID1 VID2 VID3 VID4 VID5
SYS DISP SLEEP DIRECT IN ROOM2
INTRO
RETURN
B RPT A
7.1 SURR TITLE
ENTER
HOME THEATER MASTER RV4700 DTS-ES
