Hardware orientation – RGBLink MSP 200 Quick Start User Manual
Page 5
Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: 00865925771197 Fax:00865925771202
Email: [email protected] http://www.rgblink.cn
4
Hardware Orientation
NO.
INTERFACE
NO.
INTERFACE
1
SDI Output BNC port
4
DVI+VGA Output DVI-I
2
CVBS Output
5
Switch
3
Audio Output
NO
INTERFACE
NO
INTERFACE
1
Power
5
USB Interface
2, 3
Genlock Output
6
Battery Status Indicator
4
Dial switch
7
Reset
