4-WAY GEARBOX ASSEMBLY
Rev. 1, OCT 05
ITEM PART NO. DESCRIPTION SERIAL NUMBER QTY
1 521116 BEARING 6207 3
2 521794 SHIM KIT - 48.0 6
3 521127 OIL SEAL - 35 X 72 X 10/7 2
4 521481 STUB SHAFT - 1 3/8" SPLINE 2
5 521137 SNAP RING - 35 UNI 7435 4
6 521482 3/8" PIPE PLUG 2
7 521362 BEARING - 30207 3
8 521483 HOUSING 1
9 ITEM 20 BOLT - M12 X 40 - 10.9 2
10 ITEM 20 WASHER BLANK 2
11 521486 THRU SHAFT 1 3/8" X 1 3/8" 1
12 521120 OIL SEAL - 35 X 52 X 7 2
13 521487 GEAR Z18 M5 3
14 521488 BOLT - M12 X 25 - 8.8 KIT (6 PCS) 12
15 521489 OIL LEVEL DIPSTICK 1
16 521796 EXTENSION HOUSING 2
17 - GASKET (REPLACE W/SILICONE) 3
18 521797 COVER 1
19 521491 WASHER - SHIM (60 X 72) (3 PCS) 1
20 522426 BOLT KIT - ITEMS 9 (2) & 10 (2) 1
***** 521497 COMPLETE GEARBOX 1
OL - Obtain Locally AR - As Required QTY - Total Number Required for One Gearbox
23
