WING DECK - MODEL TD65-2 - 12'
ITEM PART # DESCRIPTION 12' Serial No. QTY
1 521707 44" RH MOWER DECK 1
521706 44" LH MOWER DECK 1
2 O.L. 7/16" X 1" BOLT, LOCK, NUT 18
3 O.L. 1/4" - 28 GREASE FITTING 20
4 521315 B69 BELT (A,B,C MODELS) 4
212040 B75 BELT (D MODELS ONLY) 4
5 521818 1" GRAPH OIL BUSHING (PRESS IN) 12
521818.10 1" GRAPH OIL BUSHING 10 PACK 2
6 522312 1" X 9 3/8" CORNER PIN 9765-2342 AND ABOVE 2
521312 1" X 9" CORNER PIN 9365-2002 TO 9765-2341 2
7 521021 1" X 1" RD SPACER (6 PC/ KIT) 3 KITS
8 521022 3/8" 1" RD SPACER (6 PC/KIT) 3 KITS
9 521038RD 5/16" LYNCH PIN (4PC/ KIT) 2 KITS
10 521704 LH BELT GUARD 2
521705 RH BELT GUARD 2
11 521013 SLIDE PLATE 3
12 521004 1 1/4" SHIM WASHER (9 PC KIT) 1 KITS
13 O.L. 9/16" X 2" BOLT AND LOCK 12
14 521012 DECK GEARBOX LF141A 3
15 521390 KEY - 1/4" X 1/4" X 1 5/16" (KIT 3 PCS) 3 KITS
16 521020 1/2" X 3 1/2" TAP BOLT (3 PC/KIT) 1 KIT
17 521019 GEARBOX MOUNT 3
18 521018 STIFFENER NUT BRACKET 6
19 O.L. 3/8" WING NUT, FLAT WASHER 16
20 521703 BELT GUARD SMALL 2
21 521129 WASHER - 25 X 44 X 4 (3 PC/KIT) 1 KIT
22 521130 CASTELLATED NUT M24 X 2 3
23 O.L. 3/16" X 2 1/4" COTTERPIN 3
24 521774 MAIN DRIVE PULLEY 8.7" (A,B,C MODELS) 9465-2044 AND ABOVE 3
212021 MAIN DRIVE PULLEY 11 1/4" (D MODELS) 3
521035 MAIN DRIVE PULLEY (BLACK) 9365-2002 TO 9365-2043 3
25 209001 ANTI-SCALP ROLLER - 4 1/4" 6
26 521750 ANTI-SCALP PIN 5 7/8" + COTTERPIN 6
O.L. - Obtain Locally AR - As Required QTY - Total Number Required for Complete Machine
Rev. 2, JUNE 09
