9.4.4 Battery Cabinets
Although the individual batteries are sealed and require minimal maintenance only, the
batteries should be given a periodic inspection and electrical check every six months.
Battery Service Agreements are available through OnLine Power Customer Service and
Support at 1-800-PWR-SRVC (800-797-7782).
In order to qualify for battery warranty replacement, you will need to show records of the
battery maintenance history including battery numbers, battery voltages (individual cells),
terminal torque measurements and dates of maintenance.
9.4.5 Power Connections

Check for corrosion and connection integrity. Visually inspect wiring for discolored or
cracked insulation. Clean and / or re-torque as required.

All Battery terminal connections must be tighten with proper torque value set in
accordance with the table or instructions provided by battery manufacturer.

Use the correct torque tool to tighten the terminal bolts as indicated in table below and
use all hardware's provided with batteries.
Type – Standard VRLA Battery
Battery part number Initial torque in LBS Annual re-torque in LBS Terminal Type Hardware
PRC-12150 C
(150AH)
120 IN-LB / 13.6 NM 115 IN-LB / 13.6 NM
Copper Insert
Terminal
¼ - 20 UNC Bolt
UB 12750 88.5 IN-LB / 10 NM 84 IN-LB / 9.5 NM
Z1 "Z" post
type terminal
1 to 1.25" long bolt
w/14mm head, 14mm nut,
8mm washer & lockwasher
UB12900 88.5 IN-LB / 10 NM 84 IN-LB / 9.5 NM Same as above Same as above
UB12110 88.5 IN-LB / 10 NM 84 IN-LB / 9.5 NM Same as above Same as above
Type G – Longer warranty battery
Battery part number Initial torque in LBS Annual re-torque in LBS Terminal Type Hardware
GSLF – 10512 120 IN-LB / 13.6 NM 115 IN-LB / 13.0 NM Copper Insert ¼ "
GSLF - 12012 120 IN-LB / 13.6 NM 115 IN-LB / 13.0 NM Copper Insert ¼ "
Type N – Nickel-Cad battery (only nickel plated copper cable lugs should be used).
Ni-Cad P/N Recommended Torque Bolt Diameter
BM 112/ 138 66 IN-LB 7.5 NM M5
BM 148/ 184 177 IN-LB 20 NM M8
BM 195/231/277 266 IN-LB 30 NM M10
NOTE: For annual re-torque; reduce 5 IN-LB from recommended torque value.
CAUTION: Torque all connections in accordance with the above tables unless provided from battery
manufacturer. Failure to do so may create an unsafe condition or fire hazard.
