MovinCool Office Pro W20 - Manual (Page 36)

36
TECHNICAL SPECIFICATIONS (cont.)
• Specifications are subject to change without notice.
Note:
*1: If the entering water temperature is below 68 °F (20 °C) or above 86 °F (30 °C),
adjustment of the unit's water regulating valve setting is required.
*2: Measured at 3 feet (1.0 m) from surface of the unit.
ITEM SPECIFICATIONS
Operating Condition Range Inlet Air
Temperature
Max. 95 °F (35 °C), 60 %RH
Min. 65 °F (18 °C), 50 %RH
Entering Water
Temperature
*1
Max. 90 °F (32 °C)
Min. 40 °F (4.4 °C)
Water Pressure 150 psi (1,034 kPa) or less
Recommended Water
Flow Rate
5 gal/min (18 L/min)
Maximum Duct Length Cold Duct 25 ft (7.6 m)
Sound Level
*2 High 62 dB (A)
Low 60 dB (A)
