ME34-BV Homefire
XG0304
Introduction
About this fireplace:
Thank you for choosing a Montigo Gas Fireplace. The ME34-BV
includes a 20,000 BTU dual burner and embers. All M34 Series
Modular Fireplaces allow quick and easy upgrades in the future.
The ME34-BV can be upgraded to a Wildfire Burner. Contact your
dealer for more information. The ME34 is available in two ver-
sions:
n ME34-BV -- Standard (Continuous) Pilot
n ME34-BV-I -- Intermittent (Electronic) Pilot
The ME34-BV is certified in Canada and the USA as a Vented
Gas Fireplace Heater (ANSI Z21.88-1998 · CSA 2.33-M98) and
is rated for:
Natural Gas 20,000 BTU/H (5.86 Kilowatts) Input
14,000 BTU/H (4.1 Kilowatts) Output
Propane 20,000 BTU/H (5.86 Kilowatts) Input
14,000 BTU/H (4.1 Kilowatts) Output
How to use this manual:
This manual covers all models and unless otherwise specified, the
designation ME34-BV refers to all models. Sections which are
specific to a particular model are marked with a
symbol,
plus the appropriate model number.
Warranty and Installation Information:
The Montigo warranty will be voided by, and Montigo disclaims
any responsibility for, the following actions:
n
Modification of the fireplace and/or components including
Direct-Vent assembly or glass doors.
n
Use of any component part not manufactured or approved by
Montigo in combination with this Montigo fireplace system.
n
Installation other than as instructed in this manual.
Consult your local Gas Inspection Branch on installation require-
ments for factory-built gas fireplaces. Installation & repairs should
be done by a qualified contractor.
Installations in Canada must conform to the current CAN/CGA
B-149.1 and .2 Gas Installation Code and local regulations. If the
optional air-circulating fan kit is installed, it must be electrically
grounded in accordance with CSA C22.1 Canadian Electrical
Code Part 1 and/or Local Codes.
Installations in the USA must conform to local codes, or in the
absense of local codes to the National Fuel Gas Code, ANSI
Z223.1-1988. If the optional air-circulating fan is installed, it must
be grounded in accordance with local codes or, in the absence of
local codes, with the National Electrical Code, ANSI/NFPA 70-
1987.
Table Of Contents
Introduction ............................................................................. 2
Installation
Installing the Fireplace Shell ........................................... 3
Installing the Gasline ...................................................... 4
The Remote Switch ....................................................... 4
B-Vent Installation .......................................................... 4
Construction around the fireplace
Facing ............................................................... 5
Mantels and Surrounds ..................................... 5
Wiring .................................................................... 5 - 6
Installing the Logset ....................................................... 6
Removing and Installing the Insert ................................. 7
Removing and Installing the Door .................................. 7
Operation .......................................................................... 8 - 10
Maintenance ................................................................... 10 - 11
Warranty ................................................................................. 12
Appendix
A. Spare Parts ............................................................. 13
CAUTIONS
Due to its high operating temperatures, the appliance
should be located out of traffic & away from furniture and
draperies.
n
Children and adults should be alerted to the hazards of
the high surface temperature, which could cause burns
or clothing ignition.
n
Young children should be carefully supervised when
they are in the same room as the appliance.
n
Clothing or other flammable materials should not be
placed on or near the appliance.
