Connecting to a power source, Figure 12, Power socket – Microsens MS453490M Installation User Manual
Page 38: Onnecting, Ower, Ource

C
HAPTER
3
| Installing the Switch
Connecting to a Power Source
– 38 –
C
ONNECTING
TO
A
P
OWER
S
OURCE
To connect a switch to a power source:
1.
Insert the power cable plug directly into the AC socket located at the back of
the switch.
Figure 12: Power Socket
2.
Plug the other end of the cable into a grounded, 3-pin, AC power source.
3.
Check the front-panel LEDs as the device is powered on to be sure the
Power LED is lit. If not, check that the power cable is correctly plugged in.
N
OTE
:
SFP transceivers are hot-swappable. The switch does not need to
be powered off before installing or removing a transceiver. However,
always first disconnect the network cable before removing a
transceiver.
N
OTE
:
SFP transceivers are not provided in the switch package.
N
OTE
:
For International use, you may need to change the AC line cord.
You must use a line cord set that has been approved for the socket type
in your country.
