62 Metro TM MPE-7800 Series NiMH Power Supply Operations Manual Supplement
InterMetro Industries Corporation
Warning 14: Heat sink Over Temperature
• Power supply turns off charger.
• Air flow in the power supply may be restricted due to cooling fan not
working properly, fan blocked, or clogged ventilation slots around the
power supply case.
• Turn off computer equipment and then the power supply.
• Check that the fan is not blocked. Check the ventilation slots around the
power supply case for dust build-up and clean.
• Turn on the power supply and restart the computer equipment.
• If this problem continues, contact InterMetro Customer Service.
BatteryPro
Diagnostics
The following are the ways diagnostic information is provided by BatteryPro
when it is installed and running:
Popups BatteryPro will generate a popup message when a fault is detected. The
error may correspond to a Fuel Gauge warning shown above. Carefully
read the popup messages, since they generally contain information giving a
solution to the problem that occurs. For additional information, contact
InterMetro Customer Service.
Diagnostics A Diagnostic tab is available in the BatteryPro dialog window. Please see
“Diagnostics” under “BatteryPro Configuration and Status” above.
History Log BatteryPro generates a log stored at:
“ x:\Documents and Settings\All Users\Application Data\BatteryPro\Historylog.txt ”,
where “x” is your main computer drive (typically the “C” drive).
A fault code shows up in the log as:
“Fault Code (CMD=70):nn”,
where “nn” is fault code number from 1 to 14. Notes on the fault may
follow the fault number.
Examples:
Fault Code (CMD=70):4 = Battery Fuse Blown
Fault Code (CMD=70):14 = Heatsink Overtemperature
