October 2000 Medallion Rotate Manual
15
S
TARTING
M
EDALLION
R
OTATE AND
D
ISPLAYING
C
HANNELS
The first section of the Tutorial leads you through starting Medallion
Rotate, as well as opening a data file and displaying data channels in the file.
S
TART
M
EDALLION
R
OTATE
1. To start Medallion Rotate, click Start, point to Programs, then to
Medallion Rotate, then click Medallion Rotate. The Medallion Rotate
program window appears.
V
IEW THE
C
HANNEL
L
IST
Medallion Rotate displays the
Channel List window when it starts.
Initially the Channel List shows the 2
channels of data from the demonstration
data file.
Hint: Don’t worry if the Channels
List window is empty, or contains different files than the ones shown in
the picture. Adding files to the Channel List window is described below.
2. You can hide the Channel List window by clicking anywhere on the
Medallion Rotate window or by pressing Esc.
3. You can restore the Channel List window by doing one of the following:
• Right-click on the Medallion Rotate window.
• Press Ctrl+L.
• Click the Channel List
button .
• From the Channels menu
choose Channel List
Window.
R
EMOVE
C
HANNELS FROM THE
C
HANNEL
L
IST
Removing “channels from the Channel List window does not delete any
data, and you can add the channels back in at any time.
4. Select the 2 channels in the Channel List by holding down the Ctrl key
and clicking the two channels. You can also hold down the Shift key
and select a range of channels.
5. Press Del.
Hint: You can also right-click a
channel and choose Remove.
Note that this removes all
selected channels, not just the
one you right-clicked.
