HEIGHT ADJUSTMENT CALIPER
The caliper setting is what ensures the feeding of one sheet and prevents the feeding of
double sheets. It is very important that this caliper be set correctly. To set the caliper
take one sheet of the stock you are running and slide it between the caliper and vacuum
wheel. Take a second sheet and slide it back and forth, in and out while lowering the
height adjustment until the second sheet cannot slide under the caliper. DO NOT
OVERTIGHTEN! It is very important that the sheet is not pinched in anyway.
There are 2 different calipers; the o-ring and the metal caliper. The metal caliper is
designed to work better with heavy stock and the o-ring caliper is designed to work with
lighter stocks. Use the o-ring caliper when running any multi-part forms.
20
Height Adjustment Knob
Caliper Disk Lock Knob
