163
Surround
This unit is equipped with a digital signal processing circuit that lets you play program sources in the sound mode to achieve the same sense of presence as in a movie theater.
Sound modes and surround parameters
This table shows the speakers that can be used in each sound mode and the surround parameters adjustable in each sound mode.
Symbols in the table
S This indicates the audio output channels or surround parameters that can be set.
D This indicates the audio output channels. The output channels depend on the settings of “Speaker Config.” ( vpage 131 ).
Sound Mode ( vpage 75 )
Channel output z1 During playback in PURE DIRECT mode, the surround parameters are the same as in
DIRECT mode.
z2 Only when “Subwoofer Mode” is set to “LFE+Main” ( vpage 132 ), sound is
output from the subwoofer.
z3 A signal for each channel contained in an input signal is output as audio.
z4 Audio is output from the front height speaker when the set sound mode name
contains “+PL gz”. For information on how to check the sound mode, see page 75 .
z5 Audio is output from the front height speaker when “Assign Mode” ( vpage 131 )
in the menu is set to ”Main Only” and “Audyssey DSX®” ( vpage 117 ) is set to
“On”.
z6 Audio is output from the front wide speaker when “Assign Mode” ( vpage 131 )
in the menu is set to ”Main Only” and “Audyssey DSX®” ( vpage 117 ) is set to
“On”.
z7 Audio is output from the surround back speaker when “Assign Mode” ( vpage 131 )
in the menu is set to ”Main Only” and “Speaker Select” ( vpage 114 ) is set to “S.
Back”.
z8 Audio is output from the front height speaker when “Assign Mode” ( vpage 131 )
in the menu is set to ”Main Only” and “Speaker Select” ( vpage 114 ) is set to “F.
Height”.
z9 Audio is output from the front wide speaker when “Assign Mode” ( vpage 131 ) in
the menu is set to ”Main Only” and “Speaker Select” ( vpage 114 ) is set to “F.
Wide”.
Front
L/R
Center
Surround
L/R
Surround back L/R
Front height
L/R
Front wide
L/R
Subwoofer
DIRECT/PURE DIRECT (2channel)z1 S Dz2
DIRECT/PURE DIRECT (Multi-channel)z1 S D D Dz3 Dz3 Dz3 D
STEREO S D
MULTI CH IN S D D D Dz4 D
DOLBY PRO LOGIC gz S D D D D
DOLBY PRO LOGIC gx S D D D D
DOLBY PRO LOGIC g S D D D
DOLBY PRO LOGIC S D D D
DOLBY PRO LOGIC g A-DSX S D D Dz5 Dz6 D
DOLBY PRO LOGIC A-DSX S D D Dz5 Dz6 D
DTS NEO:6 S D D D D
DTS NEO:6 A-DSX S D D Dz5 Dz6 D
Audyssey DSX® S D D Dz5 Dz6 D
DOLBY DIGITAL S D D D Dz4 D
DOLBY DIGITAL Plus S D D D Dz4 D
DOLBY TrueHD S D D D Dz4 D
DTS SURROUND S D D D Dz4 D
DTS 96/24 S D D D Dz4 D
DTS-HD S D D D Dz4 D
DTS Express S D D D Dz4 D
MULTI CH STEREO S D D Dz7 Dz8 Dz9 D
VIRTUAL S D
