37
Figure4-12 Auto Mail Setup Interface
In this area, users can set receiver and sender’s E-mail SMTP server and
address. Note: the address of receiver and sender can be the same.
Receiver's E-mail Address
Sender's SMTP
Sender's E-mail Address
Sender's User Name
Sender's Password
E-mail Subject
Figure4-13 Auto Mail Setup
To test the settings, click ‘Send Mail Test’. If all settings are okay, response
‘Message Sent Successfully’ will pop up. If some settings are wrong, a
warning message will pop up.
Enable ‘Attachment’, then a picture of what triggered the alarm will be sent to
the selected mailbox, refer to Figure4-14.
