ELECTRICAL CHARACTERISTICS CURVES
Figure 1:
Efficiency vs. load current for minimum, nominal, and
maximum input voltage at 25°C.
70
75
80
85
90
95
0
5
10
15
20
25
30
OUTPUT CURRENT (A)
EF
F
ICI
ENCY (%)
36Vin
48Vin
75Vin
Figure 2:
Power dissipation vs. load current for minimum,
nominal, and maximum input voltage at 25°C.
DS_F48SA28025_12072007
3
