FEATURES
High efficiency: 91.5% @ 28V/25A
Industry standard size and pinout:
61.0 x 116.8 x 12.7mm (2.40”x 4.60”x 0.50”)
Fixed frequency operation
Remote sense
Input UVLO, Output OCP, OVP & OTP
Auxiliary bias power
Basic insulation
2250V isolation
ISO 9001, TL 9000, ISO 14001, QS9000,
OHSAS18001 certified manufacturing facility
UL/cUL 60950 (US & Canada) recognized, and
TUV (EN60950) certified
CE mark meets 73/23/EEC and 93/68/EEC
directive
Delphi Series F48SA, 700W Full Brick Family
DC/DC Power Module: 48Vin, 28Vout
APPLICATIONS
ipment
t
OPTIONS
extended operation
wn
Telecom / DataCom
Wireless Networks
Optical Network Equ
Server and Data Storage
The Delphi Series F48SA, 48V input, single output, full brick sized
isolated DC/DC converter is the latest offering from a world leader in
power systems technology and manufacturing ― Delta Electronics,
Inc. The Delphi F48SA series provides up to 700 watts of power or
up to 25A of output current. This product family operates from a wide
input range of 36V to 75V. With creative design technology and
optimization of component placement, these converters possess
outstanding electrical and thermal performance, as well as extremely
high reliability under highly stressful operating conditions. All models
are protected from abnormal input/output voltage and current
conditions, and feature 2250V input/output isolation and basic
insulation. An optional heatsink is available for extended operation.
Industrial / Test Equipmen
Heatsink for
Output current monitoring
Delayed overcurrent shutdo
Parallel operation using forced
current sharing
DATASHEET
DS_F48SA28025_12072007
