■ H H1 1//4 4 B BR RO OW WN N//B BL LA AC CK K:: Connect the brown/black wire
to the master switch side of the unlock wire. The master
switch side will show (+)12V when the master switch is in the
unlock position and (-) ground when the master switch is in
the middle position.
■ H H1 1//3 3 B BL LU UE E//B BL LA AC CK K:: Connect the blue/black wire to the
other side of the unlock wire.
■ H
H1 1//2 2 V VIIO OL LE ET T:: This wire must be connected to a constant
(+)12 volts. The best connection point for this wire is the con-
stant (+)12V supply for the door lock switch*, or directly to the
positive (+) battery post with a fuse at the battery post. (See both
notes above.)
*note: Except in GM cars with retained accessory power
(RAP). In these vehicles, the (+)12V feed to the door lock
switches is turned off if the doors are closed for any length
of time.
note: Most direct-wired power lock systems require 20-30
amps of current to operate. Connecting the violet/black
wire to a poor source of voltage will keep the door locks
from operating properly.
