- 46 -

BIOS

3.13 BIOS Beep Sound code list

Address

Device Description

E000:0000h - F000:FFFFh

System BIOS Area

D000:2000h - D000:FFFFh

Free space

D000:0000h - D000:1FFFh

LAN ROM

C000:E000h - CF00:FFFFh

Free space

C000:0000h - C000:DFFFh

VGA BIOS

A000:0000h - B000:FFFFh

VGA RAM

0000:0000h - 9000:FFFFh

DOS 640K

3.14 BIOS memory mapping

Beep Sound

Message

1 short (Beep)

System booting is normally

2 short (Beep)

CMOS setting error

1 long - 1 short (Beep)

DRAM error

1 long - 2 short (Beep)

Display card or monitor connected error

1 long - 3 short (Beep)

Keyboard error

1 long - 9 short (Beep)

ROM error

Long (Beep) continuous

DRAM hasn’t inset correctly

Short (Beep) continuous

POWER supply has problem
