- 26 -

BIOS

IDE Primary HDDs / IDE Secondary HDDs

The onboard PCI IDE connectors provide Primary and Secondary channels

for connecting up to four IDE hard disks or other IDE devices.

(DFKFKDQQHOFDQVXSSRUWXSWRWZRKDUGGLVNVWKH¿UVWLVWKH³0DVWHU´DQG
the second is the “Slave”.

3UHVV(QWHU!WRFRQ¿JXUHWKHKDUGGLVN7KHVHOHFWLRQVLQFOXGH$XWR
0DQXDODQG1RQH6HOHFWµ0DQXDO¶WRGH¿QHWKHGULYHLQIRUPDWLRQPDQXDOO\
You will be asked to enter the following items.

Cylinder:

Number of cylinders

Head:

Number of read/write heads

Precomp:

Write precompensation

Landing Zone:

Landing zone

Sector:

Number of sectors

The Access Mode selections are as follows:

CHS

(HD < 528MB)

LBA

(HD > 528MB and supports Logical Block Addressing)

Large

(for MS-DOS only)

Auto

Drive A / Drive B

7KHVH¿HOGVLGHQWLI\WKHW\SHVRIÀRSS\GLVNGULYH$RUGULYH%WKDWKDV
EHHQLQVWDOOHGLQWKHFRPSXWHU7KHDYDLODEOHVSHFL¿FDWLRQVDUH

None

360K, 5.25 in.

1.2M, 5.25 in.

720K, 3.5 in.

1.44M, 3.5 in.

2.88M, 3.5 in.

Video

7KLV¿HOGVHOHFWVWKHW\SHRIYLGHRGLVSOD\FDUGLQVWDOOHGLQ\RXUV\VWHP
You can choose the following video display cards:

EGA/VGA

For EGA, VGA, SEGA, SVGA or PGA monitor

adapters. (default)

CGA 40

Power up in 40 column mode.

CGA 80

Power up in 80 column mode.

MONO

For Hercules or MDA adapters.
