- 34 -
BIOS
SuperIO Device >>>
Serial/ Onboard Parallel Port
It allows you to select the onboard serial and parallel ports with their
addresses.
Setting: Serial Port 1 3F8/IRQ4 (Default)
Serial Port 2 2F8/IRQ3 (Default)
Parallel Port 378H/IRQ7 (Default)
UART Mode Select
It determines the UART 2 mode in your computer.
Setting: IrDA, ASKIR, Normal (Default).
RxD, TxD Active
Setting: Hi,Hi , Hi,Lo (Default) , Lo,Hi , Lo,Lo.
IR Transmission Delay
Setting: Disabled, Enabled (Default).
Onboard FDC Controller
Select “Enabled” if you wish to use it. Select “Disabled” if you don’t wish to
use it.
Setting: Disabled, Enabled (Default).
