speciFications
Continued
MODELS VGM42(H) AND GM42(H)
10.5"
17"
0.625"
51"
30.5"
28.5"
21.25"
41.25"
23.5"
24.25"
3.5"
13"
1"
49"
8"
58"
30"
42"
51"
12"
9.5"
8.5"
67"
11"
GAS LINE
KNOCK OUTS
AIR KIT
KNOCK OUT
LEFT SIDE
OUTSIDE AIR
1 1 /
2
" AIR SPACE
BACK AND SIDES
0" TO
BOTTOM
GAS LINE
KNOCKOUTS
12" EACH SIDE
COMBUSTIBLE
WALL BOARD
NO COMBUSTIBLE
MATERIAL ON FACE
MINIMUM 18" TO
PERPENDICULAR
SIDEWALL
HEARTH EXTENSION
66" X 20"
2" CHIMNEY AIRSPACE
CLEARANCE TO
COMBUSTIBLE MATERIAL
ROUND TOP TERMINATION
TERMINATION
SQUARE CHASE-TOP
