15
P. 4 Stitch Weld - Enables/disables stitch welding and specifies length of each weld stitch.
When OFF is selected the weld will be continuous. A numerical value specifies the
distance in inches or cm (dependant upon the unit calibration of the control) that the
carriage will travel during a stitch weld.
P. 5 No-Weld Spacing - Specifies the distance in inches or cm (dependant upon the unit
calibration of the control) that the carriage will travel between stitch welds. If the Stitch
Weld parameter is set to “Off”, then this parameter is disabled (forced to Off) and the
display variable will show “- - -“.
Factory Settings:
The following table shows the settings/values of the Programmable Parameter/Variables as
supplied from the factory:
Switch
Position
Parameter
GM-02-250
(GSP-2004-10)
Value
P. 1 Travel Motion Delay 00.3 (seconds)
P. 2 Crater Fill Delay 00.5 (seconds)
P. 3 Post Weld Delay 01.0 (seconds)
P. 4 Stitch Weld Selection Off
P. 5 No-Weld Spacing - - -
P. 6 Not Applicable - - -
P. 7 Not Applicable - - -
P. 8 Not Applicable - - -
P. 9 Not Applicable - - -
The standard equipment and functionality as described in this manual is suitable for a large
percentage of simple welding and cutting procedures, however, Gullco has many different
product/application modules, attachments and programs to accommodate more complex
applications requiring features above those provided here. Please consult your local Gullco dealer
to discuss your specific application.
