As a default the Motor Control Variables for the GSP-2010-10 will be factory pre-set as either one of
the following:
Standard Imperial Settings for GM-02-250 SAM
®
Carriages
Variable/Parameter P. 1 P. 2 P. 3 P. 4 P. 5 P. 6 P. 7 P. 8 P. 9
Value/Setting 08.0 66 10 00 _ _ . _ Inc 001 002 100
Overall Result
The control will allow a current draw of up to 8 amperes. The speed will be
calibrated so that full speed will display 66.1 IPM. The braking will be close to
instantaneous. The speed correction response will be sharp. 100% of full
speed will be available.
Standard Metric Settings for GM-02-250 SAM
®
Carriages
Variable/Parameter P. 1 P. 2 P. 3 P. 4 P. 5 P. 6 P. 7 P. 8 P. 9
Value/Setting 08.0 16 80 00 _ _ _ . CM/MIN 001 002 100
Overall Result
The control will allow a current draw of up to 8 amperes. The speed will be
calibrated so that full speed will display 168 CM/MIN. The braking will be
close to instantaneous. The speed correction response will be sharp. 100%
of full speed will be available.
The Gullco “GSP” motor controller needs to have the speed display calibrated to match that of the
equipment driven by the motor. This is required so that the speed displayed is equal to that of the
motion. The speed calibration is performed with an accuracy of six (6) digits, however, on this
specific version of the control only the first three (3) digits are required.
