Greenheck Melink IH3 Operations - Manual (Page 15)

Exhaust Fan Parameters
EFxx‐01 Primary Exhaust Output Address 1 1 to 39
EFxx‐02 Name EF‐x Up To 5 Characters
EFxx‐03 Output Type
A‐B Powerflex
4/40
System Output
A‐B Powerflex 4/40
A‐B Powerflex 400
ABB ACH550
EFxx‐04 Touchpad Display Node 1 1‐10
EFxx‐05 Exhaust CFM
Aux Airflow Parameters
AAxx‐01 Aux Airflow ID 41 40 to 128
AAxx‐02 Name Airflow‐x Up To 5 Characters
AAxx‐03 Algorithm Average Average, Highest, Lowest
AAxx‐04 Related Airflows None
List All Programmed Primary, Aux, and External
Airflows
AAxx‐05 Output Type System Output
System Output
A‐B Powerflex 4/40
A‐B Powerflex 400
ABB ACH550
AAxx‐06 VFD Address 41 1 to 256
AAxx‐07 Airflow CFM 1000 100‐100,000
AAxx‐08 Related Touchpad Display 1 None, 1‐10
Touchpad Parameters
TPx‐01 Touchpad Hood Network Address 1 1‐10
TPx‐02 Light Controller Addresses SC SC
TPx‐03 Bypass Softkey Visible Yes Yes Or No
System Parameters
SY‐01 Relay 1 Output
Damper
None
Exhaust Temp Alarm
Smoke
Fan On
MUA Damper
Temperature Fault
Optic Fault
VFD Fault
24/7
SY‐02 Relay 2 Output
SY‐03 24VDC Output 1
SY‐04 24VDC Output 2
SY‐05 Digital Input 1
None
None
Remote On/Off
Remote On/Off w/ Enable
Remote Enable/Disable
50% Min Speed
60% Min Speed
70% Min Speed
80% Min Speed
90% Min Speed
100% Min Speed
External Fault Input
SY‐06 Digital Input 2
SY‐07 Digital Input 3
SY‐08 Analog Output Function None None, Average, Highest, Lowest
