MII Connector Specifications
C
9
MII C
ONNECTOR
S
PECIFICATIONS
The MII (Media Independent Interface) is a 40 pin connector used for
making connection with other LAN networks. This connector has a shared
connection with port 2x, and when connected, the MII connection takes
operational precedence over port 2x.
The following Figure and table show the standard MII 40 pin connector and
the pin assignment.
Figure C-1. The Standard MII connector
