Identifying External Components
3
3
I
DENTIFYING
E
XTERNAL
C
OMPONENTS
This chapter describes the front panel, rear panel and LED indicators of the
Switch
Front Panel
The front panel of the Switch consists of 8 (10/100 Mbps) MDI-X ports, 1
uplink (MDI-II) port, a RS-232 communication port and LED indicators.
Figure 3-1. Front panel view of the DES-3208 Switch
♦
8 high performance N-way (MDI-X) ports all operating at 10/100
Mbps for connection to servers and hubs. All ports can be auto-
negotiated between 10Mbps or 100Mbps.
