GAI-Tronics ITR1000-001 Model ITR1000-001 Basic Tone Remote Deskset with Line Select User and Installation Manual - Manual (Page 7)

3 02/12
Description
Features and Benefits of the ITR1000-001 Basic Tone Remote Desk Set
Feature Benefit
Adjustable receive input
sensitivity and transmit output
level Allows flexibility with different radio systems and user
environments where radio output levels, line losses, and noise
factors vary.
Line receive and transmit
compression Automatically normalizes varying input and output levels caused
by system factors.
Built-in internal microphone and
speaker Allows for hands-free communication.
Intercom capability Desk set users can communicate with each other without tying up
valuable radio channels.
Selectable off-hook local speaker User can choose continuous local speaker when handset is off-
hook.
Programmable 3- or 4-frequency
function control Any one of 16 EIA standard tones can be programmed for each
frequency/function key. (4-frequency control during basic
operation; 3-frequency control during Line Select operation.)
Parallel transmit audio User can hear audio transmitted by another desk set.
Line Select
Allows selection between two separate radio channels for TX/RX
control of the three frequencies. Line Select operation is selectable
via DIP switch.
N
OTE : The unit will monitor RX audio of the selected channel
only.
Continuous monitoring Enables received audio to be broadcast over the integral speaker
when the handset is off-hook. This feature is selectable via DIP
switch.
