Maintenance
Troubleshooting
Problem Action
Power lights on the MCU
PCBA do not illuminate. 1. Verify connection of ac power cord.
2. Verify ac power is applied.
3. Verify the MCU is fully seated in the card rack.
4. Call for service of the applicable power supply.
Plug-in cards do not operate
in one of the slots. 1. Check slot with a known good plug-in card.
2. Call for service of the backplane PCBA.
Specifications
Electrical
Power supply...................................................... Each supply is fused at 2 A, 250 V (not user-serviceable)
Input voltage................................................................................................................ 120 V ac/240 V ac
Total power consumed (card dependent) ............................................................ 336 VA, 212 W maximum
Input frequency range ................................................................................................................. 50/60 Hz
Input surge current (cold start) ............................................................................Less than 40 A peak max.
Output current available: (max. not to exceed each power supply’s total output power):
(current based on convection cooling)
5 V / +/-12 V power supply................................................................. output 1 = 10 A @ +5 V dc
output 2 = 3 A @ +12 V dc
output 4 = 3 A @ -12 V dc
Total output power of each supply (50º C ambient temp. continuous)
Convection.................................................................................................................. 80 W max.
Conducted EMI ................................................................................................... Compliance to EN55022
AC input power connector (rear) ................................................................................. IEC 320-style, 3-pin
