GAI-Tronics Call/Talk Installation of Call/Talk Systems User Manual
Page 6
Pub. 42004-251A
Installation of Call/Talk Systems
Page: 6 of 9
\\s_eng\gtcproddocs\standard ioms - current release\42004 instr. manuals\42004-251a.doc
08/05
Safe Power Connection/Disconnection
The equipment will not create arcs or sparks, in normal operation, when completely installed and powered.
Installing or removing an amplifier or plugging in a live enclosure is not normal operation and can create
arcs. To guarantee safety, adhere to the following caution note.
CAUTION
Do not insert or remove equipment from the live enclosures.
A better arrangement uses a separate power disconnect.
Connect the field wiring as detailed in the instructions for the same equipment.
Call/Talk Stations
Consists
of
Station
Model No.
Description
Enclosure
Cover
Plate
Power
Supply
Speaker
Amplifier
MOD5300A Indoor Single-party Handset/ Speaker
Station
A01B B01B
C01B D01B
MOD5400A Indoor Multi-party Handset/ Speaker
Station
A01B B02B
C01B D01B
MOD5500A Indoor Speaker Amplifier Station
A01B
B04
C01B
D01B
Components are packaged separately for shipment.
