Page 9
Pub. 42004-195E
Model 491-204 Mine Dial/Page Telephone
Page:
9 of 9
f:\standard ioms - current release\42004 instr. manuals\42004-195e.doc
04/10
Typical Cable Characteristics
The table below defines cable size with cable characteristics to achieve increased operating distance and
is dependant upon the type and quality of cable utilized, optimum cable line installation and PBX.
Cable Size
DC Resistance
Inductance
Capacitance
(conductor to conductor)
Maximum
Cable Length
No. 22 AWG
16.5 ohms per
1000 feet
Maximum 0.20
µH/foot
Maximum 35 pF/foot
15,750 feet
(~3 miles)
No. 18 AWG
7.1 ohms per
1000 feet
Maximum 0.20
µH/foot
Maximum 35 pF/foot
31,500 feet
(~6 miles)
No. 14 AWG
2.8 ohms per
1000 feet
Maximum 0.20
µH/foot
Maximum 35 pF/foot
63,000 feet
(~12 miles)
Replacement Parts
Part Number
Description
10415-101
Handset
Assembly
12502-101
Replacement Receiver Kit
12504-010
Keypad Replacement Kit - Models 491-103, 491-104, and 491-204
12506-003
Speaker Replacement Kit
12567-001
Page
Switch
61507-009
Harness
Assembly/Subset
69491-002
Keypad Amplifier PCBA
69491-401
Speaker Amplifier PCBA
