54 55
GB
Fig. 13
USER CHARACTERISTICS
GAS BURNERS
FEED
TYPE PRESSURE mbar
NORM.
BURNER
Ø INJECTORS
1/100
THERMAL
CAPACITY
CONSUMPTION
Natural gas G20 20 Wok Dual
A - Ø71
4000 381
B - Ø95
Liquefied
gas
G30/G31 28-30/37 Wok Dual
A - Ø46
4000 291
B - Ø65
Electrical connection
Before connecting to the electricity supply, ensure that:
- the characteristics of the system are such as to satisfy that indicated on the registration plate applied to
the bottom of the hob;
- the system has an effective earth connection compliant with the standards and laws in force. Connection
to earth is compulsory by law.
If the appliance has no cable and/or plug, use material suitable for the absorption indicated on the
registration plate and for the working temperature. The cable must not reach a temperature higher than
50°C above room temperature in any point.
For direct connection to the network it is necessary to fit an omnipolar switch of a suitable size to ensure
disconnection of he network with a contact opening distance that allows complete disconnection in the
conditions of the overtension category III, compliant with the installation regulations (the yellow/green
earth wire must not be interrupted).
The omnipolar socket or switch must be easy to reach when the appliance is installed.
N.B.:
- The manufacturer declines all responsibility if the usual accident prevention standards and the above
instructions are not observed.
If the power cable is damaged, it must be replaced by the manufacturer or by the manufacturer’s technical
servicing network, or by a similarly qualified operator, to prevent every possible risk.
