73
DI-634M User’s Manual
D-Link Systems, Inc.
Frequently Asked Questions
Step 6: Enter the port or range of ports that are required to be open for the incoming
service.
Step 7: Click Apply and then click Continue.
Note: Make sure DMZ host is disabled.
Because our routers use NAT (Network Address Translation), you can only open a
specific port to one computer at a time. For example: If you have 2 web servers on
your network, you cannot open port 80 to both computers. You will need to configure
1 of the web servers to use port 81. Now you can open port 80 to the first computer
and then open port 81 to the other computer.
9 What are virtual servers?
A Virtual Server is defined as a service port, and all requests to this port will be redirected
to the computer specified by the server IP. For example, if you have an FTP Server
(port 21) at 192.168.0.5, a Web server (port 80) at 192.168.0.6, and a VPN server at
192.168.0.7, then you need to specify the following virtual server mapping table:
10 How do I use PC Anywhere with my DI-634M
router?
You will need to open 2 ports in the Virtual Server section of your D-Link router.
Step 1: Open your web browser and enter the IP Address of the router
(192.168.0.1).
Step 2: Click on Advanced at the top and then click Virtual Server on the left side.
Server Port Server IP Enable
21 192.168.0.5 X
80 192.168.0.6 X
1723 192.168.0.7 X
