Super IO Configuration
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Super IO Configuration
Super IO Chip IT8728
▶ Serial Port 1 Configuration
▶ Parallel Port Configuration
▶ CIR Controller Configuration
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized �efaults
F4: Save & Exit
ESC: Exit
Set Parameters of Serial Port
1 (COMA)
Advanced
► Serial Port 1 Configuration
Press to go to its su�menu and the following information will �e displayed.
► Device Settings
This item shows the resource assigned to the serial port.
► Change Settings
This item is used to select an optimal settings for the serial port.
► Parallel Port Configuration
Press to go to its su�menu and the following information will �e displayed.
► Device Settings
This item shows the resource assigned to the parallel port.
► Change Settings
This item is used to select an optimal settings for the parallel port.
► Device Mode
This item is used to change the parallel port mode.
► CIR Controller Configuration
Press to go to its su�menu and the following information will �e displayed.
► Device Settings
This item shows the resource assigned to the parallel port.
► Change Settings
This item is used to select an optimal settings for the parallel port.
