RAID CONFIGURATION
78
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
Intel(R) Rapid Storage Technology - Uption ROM - 11.0.8.1204
Copyright(C) 2003-11 Intel Corporation. All Rights Reserved.
Name:
RAID Level:
TryRAID0-1
RAID0(Stripe)
Port Drive Model Serial # Size Status
0 Hitachi HDS721616PLA PVF904Z21G2JZM 149.0GB Non-RAID Disk
1 ST380811AS 5PS1TAGW 74.5GB Non-RAID Disk
2 SAMSUNG HD161HJ S0V3J9APA30524 149.0GB Member Disk
3 ST380815AS 5RW1CA37 74.5GB Non-RAID Disk
Select 2 to 6 disks to use in creating the volume.
[↑↓]-Prev/Next [SPACE]-SelectDisk [ENTER]-Done
[ SELECT DISKS ]
0 Hitachi HDS721616PLA PVF904Z21G2JZM 149.0GB Member Disk
[ CREATE VOLUME MENU ]
[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select
5. From the hard disk list, select the previously configured RAID0 hard disks, and press
key to select them. Two signs will appear to indicate the selections. Press
to continue.
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
Name:
RAID Level:
TryRAID0-1
RAID0(Stripe)
Port Drive Model Serial # Size Status
► 0 Hitachi HDS721616PLA PVF904Z21G2JZM 149.0GB Member Disk
1 ST380811AS 5PS1TAGW 74.5GB Non-RAID Disk
► 2 SAMSUNG HD161HJ S0V3J9APA30524 149.0GB Member Disk
3 ST380815AS 5RW1CA37 74.5GB Non-RAID Disk
Select 2 to 6 disks to use in creating the volume.
[↑↓]-Prev/Next [SPACE]-SelectDisk [ENTER]-Done
0 Hitachi HDS721616PLA PVF904Z21G2JZM 149.0GB Member Disk
Intel(R) Rapid Storage Technology - Uption ROM - 11.0.8.1204
Copyright(C) 2003-11 Intel Corporation. All Rights Reserved.
[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select
[ CREATE VOLUME MENU ]
[ SELECT DISKS ]
6. It goes to “Strip Size” menu directly. Capacity automatically displays 148.1GB, and at this
time, you can not input any value in capacity as there is no additional volume available.
The available values of Strip Size range from 4KB to 128KB. The strip value should be
selected based on different applications. Some suggested choices are :
16K - Best for sequential transfer.
64K - Good general purpose strip size.
128K - Best performance for most desktops and workstations .
The default value is 128K. Press .
