PC Health Status
► Case Open Warning
This item is used to enable or disable case open warning function.
► Shutdown Temperature
This item is used to set the system temperature upper limit. When the temperature exceeds
the set value, the system will shut down automatically.
► CPU Vcore/VTT(V)/+ 3.3V/+5V/+12V/5VSB(V)/Voltage of Battery
The current voltages are automatically detected and displayed by the system.
► CPU/System Temperature
The CPU/System temperature are automatically detected and displayed by the system.
► CPU Fan/System Fan Speed
The CPU fan/System fan speed are automatically detected and displayed by the system.
► Smart fan Control
This option is used to enable or disable smart fan function. Only when this option is enabled,
you can set some correlative parameters.
► Start PWM Temperature
It allows you set a temperature value from which smart fan starts its operation.
► Start PWM Value
It allows you to set an initial PWM value to drive the fan when the temperature reaches Start
PWM value and smart fan begins its operation. The higher PWM value can achieve the faster
fan speed.
► Slope PWM Value
When temperature changes one degree celsius, the PWM will be increased or decreased
by a step value accordingly.
Phoenix - AwardBIOS CMOS Setup Utility
PC Health Status
Case Open Warning [Disabled] Item Help
Shutdown Temperature [Disabled]
CPU Vcore 1.28 V Menu Level ►
VTT(V) 1.89 V
+3.3V 3.31 V
+ 5V 5.25 V
+ 12V 11.50 V
5VSB(V) 5.12V
Voltage of Battery 3.38V
CPU Temperature 38oC
System Temperature 38oC
CPU Fan Speed 4272 RPM
System Fan Speed 0 RPM
Smart Fan Control [Disabled]
x Start PWM Temperature 35
x Start PWM Value 64
x Slope PWM Value 2
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F7: Optimized Defaults
Disabled
