PCIe Port #2 Configuration
► Gen2 High Speed Mode
This item is used to select the Generation II speed mode of PCI Express slots. Select [Auto],
RC will only advertize Generation II capability; Select [Software Initiated], the speed mode is
determined by software initiated; Select [Advertised RC], the speed mode is determined by RC
initiated; Select [Disabled], BIOS will turn off Generation II speed mode of PCI Express slots.
► Link ASPM
This item is used to select the link mode between ASPMs.
► Link Width
This item is used to set the link width between PCI Express slots.
► Slot Power Limit, W
This item is used to adjust the power limit of PCI Express slots. You can use [+]/ [-] to change
the value or directly input a value from 0 to 255.The default option is [75].
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
PCIe Port #2 Configuration
Gen2 High Speed Mode Help Item
Link ASPM [Disabled]
Link Width [Auto] Enable Gen2 speed
Slot Power Limit, W [75] based HW or SW
support
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F2/F3:Change Colors F9:Optimized Defaults
[Auto]
