POWERWAGON
™
Safety & Operating Instructions 17
Lubrication
Supplies Needed:
• #2 lithium grease
• FLUID FILM
®
or similar lubricant
!
WARNING: Always
disconnect the spark plug wire
before servicing your machine.
1. There are two grease fittings on
the swivel wheel: one at the top
front of the wheel bracket
(Figure 13), and one toward the
center of the wheel (Figure 14).
Occasionally grease these two
fittings with #2 lithium grease
to keep the wheel spinning
freely.
2. Lubricate the brake lever and
cable at the operator's end, the
throttle lever and cable at both
ends, and the key switch, with
FLUID FILM
® or similar
lubricant (Figure 15).
Transmission
The transaxle is factory sealed. It
contains 16 ounces of 90 weight
gear oil. No lubrication or other
servicing is necessary for the life
of the unit unless leakage occurs.
Figure 13
Figure 14
Figure 15
